DS-KH6320-WTE1-W is a modern touch monitor dedicated for the second generation Hikvision IP video intercoms systems. The monitor allows direct audio/video conversation with people at the door station and intercom communication between other monitors (indoor stations) installed in the system. This way, the users/residents can communicate one with another for free. The system is operated with a transparent and intuitive graphical interface. The monitor allows the user to connect and view images from IP cameras and gate stations at any time. It is also possible to capture a photo during a video call and record a short message if you miss a call. The monitor is equipped with an Ethernet port for network connection. The built-in 2.4 GHz Wi-Fi module enables wireless connectivity. The monitor can be powered from a 12 VDC source or via PoE (802.3af).

Key features:

• 7″, TFT LCD color touch screen with a resolution 1024 x 600 px
• operated via UI v2.0 graphical interface
• built-in speakers and microphone
• monitoring video from door/gate station and other IP cameras
• clear sound thanks to echo and noise cancellation
• management with iVMS-4200
• access and remote opening using iVMS-4200, Hik-Connect app
• additional functions: intercom, voice messages, saving images
• capturing photos during the tenant absence
• built-in memory: 128 MB
• support for microSD cards up to 32 GB
• 8 alarm inputs and 2 alarm outputs
• built-in 2.4 GHz Wi-Fi module (IEEE 802.11 b/g/n)
• network interface: RJ-45 10/100 Base-T
• 12 VDC or PoE (802.3af) power supply
